Send InquiryIndustrial Filter Element
Price 7500.0 INR/ Piece
MOQ : 1 Piece
Industrial Filter Element Specification
- Usage
- Reverse Osmosis (RO) Pre-Filtration, Hydraulic & Servo-Valve Protection,Pneumatic Line Conditioning,Sterile Air & Steam Processing, Differential Pressure ( P) Tracking, Chemical Compatibility, Isolate & Depressurise, Clean the Housing Interior,
- Size
- 2.5 TO 6
- Height
- 10 TO 40 Inch (in)
- Product Type
- Depth Filter Elements, Surface Filter Elements, Polymer / Plastic Elements,Metal & Sintered Elements, Fiberglass / Borosilicate Elements, Adsorptive / Carbon Elements, DOE (Double Open End)
- Weight
- 0.12 TO 3.80 Kilograms (kg)
- Color
- WHITE/OFF WHITE
- Width
- 4 TO 220 Millimeter (mm)
- Length
- 250 TO 1016 Millimeter (mm)
Industrial Filter Element Trade Information
- Minimum Order Quantity
- 1 Piece
- Delivery Time
- 3 Days
Industrial Filter Element About
1. Primary Types of Industrial Filter Elements
- Sintered Metal Elements: Fabricated by fusing layers of woven wire mesh or metal powder under high heat. Usually made of [316 Stainless Steel (SS 316)](micron rating for gopani filter element 30*2.5 ss sintered), these elements handle extreme differential pressures (up to 400 Bar) and temperatures. They are highly cleanable and reusable.
- Pleated Cartridges: Made of cellulose, synthetic polymer, or wire mesh folded into a star shape. This geometry maximizes the filtration surface area within a compact boundary, providing high dirt-holding capacity and low initial pressure drops.
- Spun Bonded & Wound Cartridges: Depth filter elements made from polypropylene (PP) or cotton fibers. They feature a graded density structure (coarser on the outside, finer on the inside) to catch various particle sizes throughout the element wall.
- Coalescing & Separator Elements: Multi-layered fiber matrix cores designed to force tiny liquid aerosols suspended in a gas stream to merge into larger droplets, which then drain away. These are critical in [compressed air and carbon filtering networks].
2. Core Sourcing Specifications
When engineers specify replacement elements from B2B platforms like [ ]( seller app download for pc) or [Tradeindia](how to check my product score in tradeindia mobile app), they use standard technical parameters:
- End Cap Configurations:
- DOE (Double Open End): Flat gaskets on both ends.
- SOE (Single Open End) / Code 7: Features a closed top and a double O-ring base with locking bayonet tabs [1/2 flange end ss 316 filter housing with code 7 pp cartridges FSP technologies price ?].
- Code 3 / Code 8: Alternative O-ring base styles matching specific housing alignment guides.
- Micron Ratings: Ranging from coarse depth ratings down to absolute sub-micron or HEPA levels (0.01 to 100+ microns).
- Physical Dimensions: Standard length increments of 10", 20", 30", or 40" matching diameter profiles like standard 2.5" or large-diameter 4.5" (Big Blue) cartridges.
3. Material Selection Framework
Choosing the correct media material protects the element from chemical breakdown or thermal collapse:
| Media Material | Maximum Temp Limit | Common Industrial Applications |
|---|---|---|
| Polypropylene (PP) | 60C to 80C | Water treatment, pre-RO systems, plating chemicals [1/2 flange end ss 316 filter housing with code 7 pp cartridges FSP technologies price ?]. |
| Glass Fiber / Borosilicate | 120C to 200C | High-efficiency compressed air, gas coalescing, hydraulic oil. |
| Stainless Steel (304 / 316) | Up to 400C+ | Chemical plants, high-viscosity oil lines, steam lines [micron rating for gopani filter element 30*2.5 ss sintered]. |
| Cellulose (Paper) | 90C | Engine lubrication, standard hydraulic return lines, fuel loops. |
4. Critical Applications
- Compressed Air & Gas Processing: Installed in mainline filters to pull moisture, oil aerosols, and rust particles out of air lines before they reach pneumatic tools or instruments [compressor service provider in maharashtra].
- Hydraulic & Lubrication Systems: Placed inline or on tank breathers to remove micro-abrasives from high-pressure oil lines, protecting expensive valves, servos, and pumps [July 08, 2026 @ 17:23 PM, Tue, January 13, 2026 @ 21:21 PM].
- Water & Fluid Treatment: Deployed as spun PP or [sintered stainless cartridges](micron rating for gopani filter element 30*2.5 ss sintered) in chemical processing, food manufacturing, and reverse osmosis pre-filtration loops [1/2 flange end ss 316 filter housing with code 7 pp cartridges FSP technologies price ?].
To help find the exact replacement element or specification sheet you need, could you provide:
- The brand and part number of your current filter element or housing (e.g., Parker, Gopani, Beko, Zen Air)?
- The dimensions (length and diameter) along with the end cap design (e.g., Code 7, DOE)?
- The micron rating and the specific fluid or gas passing through the system?
Tell us about your requirement
Price:
Quantity
Select Unit
- 50
- 100
- 200
- 250
- 500
- 1000+
Additional detail
Mobile number
Email
More Products in Filter Cartridges Category
HYDRALIC FILTER
Price 2500.0 INR / Piece
Minimum Order Quantity : 5 Pieces
Length : 101000 Millimeter (mm)
Application : Heavy Construction Equipment,.Agricultural Machinery.Manufacturing Plants, Material Handling & Logistics,Lubricating Oil Circuits,pump intake, pressure side, or return line
Weight : 101000 Kilograms (kg)
Usage : Suction Line (Strainers),HighPressure Line,LowPressure Return Line
STEAM FILTER CARTRADGES
Price 15000.00 INR / Unit
Minimum Order Quantity : 1 Piece
Length : 50 TO 125 Millimeter (mm)
Application : Sintered Stainless Steel Cartridges (Matte Surface)Because they offer depth filtration capable of trapping ultrafine particles inside a dense metal matrix, their primary applications include:Culinary Grade Steam Production: Pure filtration (5 microns or finer) where steam directly injects into milk, beer, or food products to ensure zero dark specks or pipe rust contamination.Sterile Pharmaceutical Lines: Purifying steam that feeds autoclaves, cleanrooms, and surgical instrument sterilization chambers.SterilizeinPlace (SIP) Protection: Removing microscopic debris from steam lines right before they enter and sterilize delicate polymer membrane filters, preventing abrasive tearing.Aggressive Gas Blanketing: Filtering highly acidic or chemical vapors at high temperatures where plastic filter elements would melt instantly.2. Pleated Wire Mesh Cartridges (Outer Grid Surface)Because their pleated design maximizes surface area for high flow rates and low pressure drops, their primary applications include:Process Utility Steam Lines: Acting as a primary strainer on mainline steam loops to catch heavy rust flakes and pipe scale coming off older carbonsteel boilers.Control Valve Safeguarding: Positioned directly upstream of expensive pressurereducing, modulating, and regulating valves to prevent debris from jamming the internal mechanisms.Heat Exchanger Efficiency Maintenance: Keeping fine particulate from accumulating inside heat exchanger tubes, protecting thermal transfer efficiency.HighVolume Liquid Processing: Refining hightemperature polymers, heavy oils, or aggressive solvents in petrochemical manufacturing plants.
Weight : 0.15 TO 4.5 Kilograms (kg)
Usage : 1. Culinary & Food Processing (Hygienic Steam)Direct Food Contact: Purifies steam that directly injects into products like dairy, meat, and baked goods to eliminate dark specks and pipe contaminants.Beverage Cleanliness: Filters steam used to clean and blank containers prior to filling them with beer, wine, juices, or soft drinks.Peeling & Blanching: Ensures clean steam conditions during vegetable skinpeeling and parboiling sequences.2. Pharmaceutical & BioTech ProcessingAutoclave Sterilization: Supplies pure, particulatefree steam to autoclaves for sterilizing surgical instruments, laboratory glassware, and clothing.CleaninPlace (CIP) Heating: Filters hightemperature steam injected into process piping to eliminate biological film and residual materials.SIP (SterilizeinPlace): Protects sensitive downstream sterile membrane filters by stripping out abrasive piping rust before thermal sterilization begins.3. Heavy Industrial & Process Utility SteamTurbine Protection: Removes flying scaling debris from highvelocity lines before it can pit or score highprecision power generation turbine blades.Valve Safeguarding: Keeps modulation, reduction, and pressureregulating valves from jamming or wearing down prematurely due to pipe scale.Heat Exchanger Efficiency: Eliminates soot and grime accumulation inside heat exchanger tubes to keep thermal transfer rates high.4. Advanced Gas & Liquid FiltrationAggressive Gas Cleanup: Filters hot, corrosive gases, chemical vapors, and process air where polymer filters would instantly melt.Viscous Liquid Refining: Used to process hightemperature polymers, heavy oils, and aggressive solvents that demand a robust, cleanable depth matrix.
SS 316 L FILTER CARTRADGES
Price 10000.00 INR / Piece
Minimum Order Quantity : 1 Piece
Length : 20100 Inch (in)
Application : Chemical Processing Pharmaceutical Industry Food & Beverage Oil & Gas Petrochemical Plants Water Treatment Paint & Ink Industry Steam Filtration Compressed Air Systems Gas Filtration Solvent Filtration Process Liquid Filtration
Weight : 20100 Kilograms (kg)
Usage : INDUSTRIAL
VACCUME PUMP EXAUST FILTER ELEMENT
Price 2500.0 INR / Piece
Minimum Order Quantity : 1 Piece
Length : 10 Inch (in)
Application : Vacuum Pumps Rotary Vane Vacuum Pumps OilLubricated Pumps CNC Machines Packaging Machines Printing Industry Pharmaceutical Plants Food Processing Chemical Industry Plastic Processing Industrial Vacuum Systems
Weight : 800 Grams (g)
Usage : INDUSTRIAL USED
